Door Insect Screen – BREEZE
Insect screen swinging door in aluminium frame
- Made in Northern Europe
- Lifespan 10+ years
- Weather-resistant
- Various installation options
- Custom-made to your exact dimensions
Custom-made insect screen door for terrace, balcony, and garden entrances. Mounts on the outside of the door frame with hinges – opens and closes like a regular door, left or right hand as needed.
The aluminium frame includes a bottom brush seal that closes the gap at the threshold. Built for frequent daily use and outdoor conditions – designed to last 10+ years.
Installs in approximately 30-40 minutes with a PZ2 screwdriver. Two mounting options available: front screws or side screws.
Available in 5 frame colours and 3 mesh types (+ Pet Screen – pet-proof durability mesh available as lower-panel-only upgrade).
A smart, durable solution for peaceful, insect-free living – season after season.
- All measurements must be taken and entered in millimeters (mm). 94cm = 940mm
- Measure carefully and each door individually – even if they look identical.
- Do not use a ruler or tailor’s tape. Always use a steel tape measure for accurate results.
Recommended - Installing onto the door frame
1. Measure the opening width (W)
Measure the clear space inside the door frame.
Just make sure the frame itself is at least 38mm wide on both sides.
2. Measure the opening height (H)
Again, measure the clear height of the opening.
Ensure you have at least 38mm of frame surface at both the top and bottom.
3. Check the layout
The red lines in the diagram show exactly where your new screen door will be mounted.
Note: The inner edges of the finished screen will match your opening, but keep in mind the total outer size will be 38mm larger on each side to allow for mounting.
Optional – Recess Mount: Installing inside the door opening
1. Measure the width of the door opening at the top (W1) and the bottom (W2)
If the two numbers don’t match, use the smaller one. If there’s a slight gap when you install the screen, you can easily fill it with a sealant or weatherstripping.
2. Measure the total height (H) of the door opening
Make sure the door frame is at least 22mm wide on all sides.
For this mounting style, the final product will be manufactured to these exact total dimensions.
Not sure about your measurements?
Send us a few photos of your window or door via chat or the contact form — our consultant will help you and recommend how to take measurements correctly. For free.
What’s in the box: Screen door, aluminum frame, mounting screws.
1. Lift the door out of the frame.
2. Place the screen on the outside of the door frame with the green sticker at the top. Mark the screw locations.
3. Drill holes at the marked locations using a 2.5 mm drill bit.
4. Screw the screen to the door frame using the included PZ2 3.5 mm screws.
5. Place the screen door onto the screen frame, aligning the two green stickers.
6. Hang the door back into the hinges.
Standard - Essential Insect Protection
Economy PVC mesh provides highly effective protection against insects thanks to a mesh size of 1.48 x 1.58 mm with 60% transparency and good air circulation at the same time. This fabric has been tried and tested a million times over for years and is widely used in all insect screen types.
- Mesh opening: 1.41 × 1.58 mm
- Transparency: 60%
- Tear-resistant and weather-resistant
- Thermofixed crossing points – no fraying
- Black – minimal visual impact
Transpatec - Nearly Invisible Screen
The finest mesh in our range. Finer openings than Standard for better insect protection, combined with exceptional transparency and airflow. Feels like the window is open.
- Mesh opening: 1.27 × 1.34 mm
- Transparency: 80%
- Airflow: ~140% better than standard mesh
- Self-cleaning coating – low maintenance
- PVC-free, solvent-free production
Polltec - Pollen & Allergy Protection
Designed specifically for allergy sufferers. The elongated mesh geometry, combined with an electrostatic coating, captures and holds pollen while maintaining significantly better airflow than conventional pollen screens.
- Mesh opening: 1.37 × 0.41 mm
- Transparency: 33%
- Pollen filtration: up to 99% (wind speed and pollen size dependent)
- Airflow: up to 3× better than standard pollen fabrics
- ECARF certified
Where to Install
Insect screen door is designed for swing doors leading to a terrace, balcony, or garden — anywhere you go in and out frequently. If you have pets, consider upgrading the lower panel to Pet Screen: it’s more visible to animals and resists scratching better than standard mesh. Note: Pet Screen handles everyday contact, but cannot withstand sustained pressure or impact from large dogs.
Cleaning
Vacuum regularly with a soft brush attachment to prevent dust buildup. For deeper cleaning: remove the door, place it flat in a bathtub or on the lawn, and rinse with a garden hose. If dirt remains, scrub gently with a soft brush and mild soapy water. No solvents, no abrasive cleaners.
Removal & Storage
It is not necessary to remove the screen for the winter season.
If you still wish to remove it, pull the metal pins from the door hinges and lift the door out of the frame. No tools needed. Store flat in a dry place if removing for winter.
Take care of your screen and it will take care of you – season after season.
Still unsure? Contact us directly – we reply same day.
More questions? Visit our full FAQ page →
